305W 310W 315W 320W Factory Price Poly Crystalline Longi Solar Panel with CE Certificate

Basic Info.

Model NO.	NB-SP-390
Application	Light Industry
Condition	New
Certification	ISO, CE
Material	Polycrystalline Silicon
DC	1000
Carton	2PCS
Panel Type	Solar System Panel
Cell	Poly
Type	Half Cell
Frame	Aluminium
MOQ	100watt
Working Life	Long
Sample	Provide
Weight	18kgs
Module Efficiency	High
Certificate	CE
Power	300W
IP Rate	IP65
Voltage	41.5
Transport Package	Carton Package
Specification	195699235mm
Trademark	Autex/OEM
Origin	China
Production Capacity	1200/Day

Packaging & Delivery

Package Size 2056.00cm * 1092.00cm * 55.00cm Package Gross Weight 23.000kg

Product Description

305W 310W 315W 320W factory price poly crystalline solar panel with CE Certificate

305W 310W 315W 320W Factory Price Poly Crystalline Longi Solar Panel with CE Certificate

Type of Module	NB-305W	NB-310W	NB-320W	NB-330W
Maximum Power	305	310	320	330
Tolerance	±3%	±3%	±3%	±3%
Open Circuit Voltage	43.9	44.2	44.6	45.1
Short Circuit Current	8.82	8.92	9.11	9.29
Maximum Power Voltage	36.3	36.5	36.9	37.3
Maximum Power Cuurent	8.4	8.49	8.67	8.85
Module Efficiency	15.7	16	16.5	8.85
Solar Cell Efficiency	17.77	18.07	18.65	19.23
Series Fuse Rating	15	15	15	15
IP Rating	IP65
Maximum System Voltage	DC 1000
Operating Temperature	-40-85ºC
Dimension	*195699235mm*
Weight	22KGS/PCS
Packing	2 pcs/carton or 26 pcs/per pallet

305W 310W 315W 320W Factory Price Poly Crystalline Longi Solar Panel with CE Certificate

Glass

Antireflective glassTranslucency of normal luminance is increased by 2%Module efficiency is increased by 2%Self-cleaning functionService life is as long as 25 years (30 years optional)

Solar Cell

High Efficiency PV CellsAppearance ConsistencyColor sorting ensure consistent appearance on each moduleAnti-PID

Frame

Conventional frameSilver or black frames are optionalBoost bearing capability and prolong service lifeSerrated-clip design tensile strengthSeal-lip designglue injection

Junction box

Conventional standalone edition and engineering custom editionQuality diode ensures module running safetyIP67 protection levelHeat dissipation

305W 310W 315W 320W Factory Price Poly Crystalline Longi Solar Panel with CE Certificate

Half Cell module technology

By using half a battery, the current in each busbar is halved. The internal loss in a half cut module is 1/4 that of a full size battery module.

Less Shading Loss

Shading loss of half-cell is much better than normal module in certain shading conditions.

Half-cell technology

The Half-Cell design ensures improved coloring response, resulting in higher yields when partially coloring modules. Under certain shading conditions, semi battery modules experience much better shading losses than traditional modules.

Low Working Temperature
Half cell module reduced by about 2 degrees

305W 310W 315W 320W Factory Price Poly Crystalline Longi Solar Panel with CE Certificate

Jiangsu autex construction group is a collectivized enterprise integrating design, production and construction.The group has six subsidiaries: jiangsu autex transportation equipment co., LTD., jiangsu autex lighting engineering co., LTD., jiangsu autex landscape engineering co., LTD., jiangsu autex electric power engineering co., LTD., jiangsu autex intelligent technology co., LTD., jiangsu autex design co., LTD. The group's main products: street lights, smart street lights, traffic lights, traffic guardrail, traffic signs, electronic police, bus shelter, photovoltaic modules, lithium batteries, road lamp poles, LED light source, wire and cable production and sales. The group has more than 20 construction and design qualifications. More than 50 professional project managers. Every Autex person will be in good faith, professional, high quality, high efficiency as the criterion, make every effort. The group is willing to work with people of insight from all walks of life hand in hand, win-win cooperation, create brilliantJiangsu autex construction group is a collectivized enterprise integrating design, production and construction.

305W 310W 315W 320W Factory Price Poly Crystalline Longi Solar Panel with CE Certificate

Q: What is a photovoltaic (PV) system design?
A: Photovoltaic (PV) system design refers to the process of determining the components and specifications needed for a solarenergy system that meets specific energy needs and requirements.
Q: What are the factors to consider when designing a PV system?
A: The factors to consider when designing a PV system include location, shading, orientation, slope, electricity consumption, budget,and local regulations.
Q: How do I determine the size of a PV system?
A: The size of a PV system can be determined by considering the energy consumption, the amount of available space for panels, andthe budget for the system.
Q: What is the difference between a grid-tied and an off-grid PV system?
A: A grid-tied PV system is connected to the main electricity grid and sends excess energy generated back to the grid. An off-grid PVsystem is a standalone system that is not connected to the main electricity grid and stores energy in batteries for later use.
Q: What is the impact of shading on a PV system?
A: Shading can significantly impact the performance of a PV system by reducing the amount of sunlight reaching the panels. Properdesign and positioning of panels can help minimize the impact of shading.
